Key Features
• Large LCD digital display with heating temperature, rotation speed, clockwise and Anti-clockwise, time information;
• One-click automatic motor lifting (stroke 180mm), smooth and silent;
• Water/oil heating bath with wide temperature range from room temp to 180°C;
• Speed range from 10 to 150rpm, and interval operation in clockwise and anticlockwise directions for drying process;
• Double-layer high-efficiency condensing tube with large condensation area and strong evaporation capacity, ensuring efficient sample recovery;
• Patented PTFE double sealing ring with excellent sealing performance；
• A switching valve for continuous collection without compromising the system vacuum and solvent distillation.
| Specifications | RE200-Pro |
| Performance | Temperature range | Room temp. ~180℃
(both water and oil) |
| Control Accuracy | Water: ±1℃Oil: ±3℃ |
| Rotation Speed | 10~150rpm |
| Evaporation capacity | Max.4.0L/h (water vapor volume) |
| Ultimate vacuum | Less 2.6hpa |
| function | Temperature control method | Micro processer PID control |
| Display | LCD (temperature/speed/clockwise and Anti-clockwise/time) |
| Stroke Displacement | Automatic 180mm |
| Safety features | Motor over-current protection, Residual Current Device,
lifting overload protection, Boil-dry protection,
over-temperature protection |
| constitute | Sample flask | Round flask 20L |
| Receiving flask | Round flask 10L with drain valve |
| Condenser | Two-section vertical triple serpentine condenser,
cooling surface 1.2m2 |
| Specification | Heating bath size | φ450×240mm |
| Takeover caliber | Cooling/suction nozzle outer diameter 16mm,
vacuum pump nozzle outer diameter 16mm |
| Dimension[D×W×H] | 1160mm×600mm×1860mm |
| Power supply | 220V/4600W/50/60Hz |
