Key Features
• LED display for precise monitoring of temperature
• A wide speed range of 0 to 1500rpm
• Max. Heating plate temperature 550°C
• External temperature control is possible by connecting the temperature sensor(PT1000) with accuracy at ±0.2°C
• The “HOT” warning will flash if the work plate temperature is above 50°C
| Specifications | MS7-H550-S |
|
| Work plate Dimension [W x D] | 184x184mm (7 inch) |
|
| Work plate material | Glass ceramic |
|
| Motor type | Shaded pole motor |
|
| Motor rating input | 15W |
|
| Motor rating output | 1.5W |
|
| Power | 1030W |
|
| Heating output | 1000W |
|
| Voltage | 100-120/200-240V 50/60Hz |
|
| Stirring positions | 1 |
|
| Max. stirring quantity, [H2O] | 10L |
|
| Max. magnetic bar[length] | 80mm |
|
| Speed range | 0-1500rpm |
|
| Speed display | Scale |
|
| Temperature display | LED |
|
| Heating temperature range | Room temp.-550°C, increment 5°C |
|
| Temperature control accuracy | ±10°C |
|
| Overheating protection | 580°C |
|
| Temperature display accuracy | ±1°C |
|
| External temperature sensor | PT1000 (accuracy ±0.2) |
|
| "Hot" warning | 50°C |
|
| Protection class | IP21 |
|
| Dimension [WxDxH] | 215x360x112mm |
|
| Weight | 4.5kg |
|
| Permissible ambient temperature and humidity | 5-40°C, 80%RH |
